CI PROv2 5-1/2" 2 Way LCR  Shallow Enclosure In-Wall

PARADIGM

CI PROv2 5-1/2" 2 Way LCR Shallow Enclosure In-Wall

Sale price$1,749.99
SKU: CIProP3-LCRv2
Quantity:
Pickup available at Precision Audio & Video Experts Storefront Usually ready in 24 hours

CI PROv2 5-1/2" 2 Way LCR Shallow Enclosure In-Wall

Precision Audio & Video Experts Storefront

Pickup available, usually ready in 24 hours

87 Sunset Blvd
Stevens Point WI 54481
United States

+17153438000

Aluminum Magnesium Ceramic (AL-MAC™) Tweeter with Exclusive Perforated Phase-Aligning (PPA™) Tweeter Lens

AL-MAC™ is our unique blend of Aluminum, Magnesium, and Ceramic materials; each of which contribute to the end goal of greater accuracy and realism. Their special properties contribute to the final product which is not only strong and lightweight, but embodies a natural anti-resonance to ensure the tweeter doesn’t just sound good “on paper” but truly sounds incredible in the real world.



CARBON-X™ Cones

Paradigm’s exclusive CARBON-X™ Cone combines lightweight stiffness with high consistency for a greater degree of accuracy and smooth, uncolored frequency response. Drivers feature long excursion voice coil motors for greater power handling and reduced power compression.

Advanced
Shock-Mount™ System

mechanically decouples the die-cast aluminum baskets from the specially formulate CARBON-X™ ingrained baffles reducing performance-robbing vibrations and resonance between the chassis and the acoustic platform. Without these resonances, all drivers are left free to deliver pure, unaltered sound with no audible distortion.



Patented† Active Ridge Technology (ART™) surrounds

Made in-house and over-moulded directly onto each cone, achieve greater excursion for a 3dB gain in distortion-free output (50% greater) compared to drivers with standard surrounds. † US patents: D654,479S and 8,340,340B2.





DESIGN 3-driver, dual passive radiators, 2-way, shallow enclosure in-wall design, Advanced SHOCK-MOUNT™ System
CROSSOVER 2nd-order electro-acoustic at 2.2 kHz
HIGH FREQUENCY DRIVER 1” (2.5cm) Aluminum Magnesium Ceramic (AL-MAC™) Tweeter with Exclusive Perforated Phase-Aligning (PPA™) Tweeter Lens and Reduced Edge Diffraction (RED™) Technology
FREQUENCY RESPONSE ON-AXIS ±3 dB from 86 Hz - 22 kHz
FREQUENCY RESPONSE 30° OFF-AXIS ±3 dB from 86 Hz - 19 kHz
MID/BASS FREQUENCY DRIVER Two 5.5” (13.9cm) CARBON-X™ Cone with overmolded Active Ridge Technology (ART™) surround, Advanced SHOCK-MOUNT™ System, FEA-Optimized Ultra Rigid Cast-Aluminium Baskets
SENSITIVITY ROOM / ANECHOIC 93 dB / 90 dB
LOW FREQUENCY EXTENSION 66 Hz
SUITABLE AMPLIFIER POWER RANGE 15-120 W
MAXIMUM INPUT POWER 90 W
IMPEDANCE Compatible with 8 ohms
WEIGHT 19.0 lbs (6.8 kg)
FINISHES White, paintable grille, black speaker
PASSIVE RADIATORS Two 5.5” (13.9cm) CARBON-X™ Cone with overmolded Active Ridge Technology (ART™) surround, Advanced SHOCK-MOUNT™ System, FEA-Optimized Ultra Rigid Cast-Aluminium Baskets
CUT-OUT DIMENSIONS 31” x 6-5/8” (78.7cm x 16.8cm)
MINIMUM MOUNTING DEPTH
(DEPTH REQUIRED IS THE DISTANCE BETWEEN 1/2" DRYWALL, OR SIMILAR MATERIAL.)
3-7/8” (9.8cm)
DIMENSIONS HXWXD (INCLUDES GRILLE).

32” x 7-5/8” x 4-1/8” (81.3cm x 19.4cm x 10.5cm)
